Catalina 315

Phone: ​​​​​​​1-800-270-2903

Price: Call for Price

Year: NEW

LOA: 33′ 0″

Location: Factory Order

The new Catalina 315 continues moving the Catalina brand to a higher level of performance, finish and engineering achievement. The 315 sails into the global marketplace with all the style and refinement of the larger Catalina 5 Series boats.

With core attributes of the award-winning 445 and 355, the 315 includes features that are not found in many of the world’s yachts, yet come standard with the Catalina 5 Series: a watertight StrikeZone™ collision bulkhead, the SecureSocket™ mast support system that affords superior load resolution and watertight integrity; the DeepDefense™ rudder system for failsafe steering, and the T-Beam MastStep™ structure that has all the benefits of a deck-stepped mast and the strength of a keel-stepped mast.

All the best elements of the 5 Series Catalinas are replicated in the 315. You’ll find a bold emphasis on strength, lead keels, sleek low profile cabin design, ergonomically correct cockpits that are optimized for efficiency, with great visibility from the helm. Plus, all the classic warmth and ambience that only a teak interior creates.

Follow us on Instagram and Facebook for more updates!

Specifications for: CATALINA 315

PRINCIPLE CHARACTERISTICS

Length Overall: 33′ 0″

Length of Hull : 31′ 0″

Length at Waterline: 26′ 6″

Beam: 11′ 7″

Mast Height Above Waterline: 14.70 m 48′ 3″

Draft:
Fin Keel 1.91 m 6′ 3″
Wing Keel 1.32 m 4′ 4″

Ballast:
Fin Keel 1,814 kg 4,000 lbs
Wing Keel 1,996 kg 4,400 lbs

Approx. Basic Weight:
Fin Keel 4,627 kg 10,200 lbs
Wing Keel 4,808 kg 10,600 lbs

Engine: 3 Cylinder Diesel 21 HP

Total Water Capacity: 41 gal

Fuel Capacity: 25 gal

Holding Tank Capacity: 17 gal

Sail Area:
100% Foretriangle 47 sq. m. 506 sq. ft.
Standard 135% Genoa 54.72 sq. m. 589 sq. ft.



Construction
  • Hull of Hand-laid Fiberglass with Structural Grid and
  • Fiberglass Hull Liner bonded to the Hull. Vinylester resin barrier coat to resist Osomatic blistering.
  • Deck of Hand –laid cored Fiberglass with a Full
  • Fiberglass Headliner
  • Molded-in Non-skid
  • Lead Fin Keel with Stainless Steel Attaching Bolts
  • Five Year Gel Coat Blister Protection * ( 2 )
  • Five Year Hull Structure Warranty * ( 3 )
  • Molded-In-Gel Coat Waterline, Midwatch Blue
  • Midwatch Blue and Silver Stripes
  • Collision bulkhead at bow with “Strike Zone”
Spars and Rigging
  • 135% Genoa, with U.V, Protection, White
  • Complete Standing and Running Rigging
  • Internal Low-Stretch Dacron Halyards
  • PVC Wiring Conduit with Messenger in Mast
  • Selden In-Mast Furling System; Double Spreader
SAIL HANDLING AND EQUIPMENT
  • ( 2 ) Two-Speed Self Tailing Primary Winches
  • ( 2 ) Two-Speed Self Tailing Mainsheet/Halyard Winches
  • Mid-boom Sheeting with Multi-Purchase Traveler
  • ( 1 ) 10 ” Winch Handle, ball bearing
  • Mainsheet Traveler with Car and Adjuster System Led to Cockpit
  • Headsail Furling Gear
  • Boom Vang, Rigid Adjustable Type
  • Inboard Genoa Tracks
  • Vertical Battens in Mainsail
PROPULSION, STEERING & CONTROLS
  • Single Lever Engine Controls on Pedestal
  • Steering Brake
  • Yanmar ( 3 ) Cylinder Diesel Engine, 21 HP Fresh
  • Water Cooled with Reduction Gear
  • Bronze Propeller, Three Blade
  • Sea Water Filter System for Engine Cooling
  • Instrumented Engine Panel mounted on Edson Pedestal with a S.S. Guard
  • 5 ” Illuminated Compass
  • Emergency Tiller Access and Emergency Tiller
  • 32 ” Stainless Steel Wheel
  • Bilge Blower
  • Hand Laminated Rudder with 316 Stainless Steel Core and Post
  • Extruded Aluminum Toe Rail
Deck Hardware
  • Comfortable Cockpit with Contoured Coamings
  • Walk Through Stern
  • Transom Boarding Platform
  • Telescopic Stern Boarding Ladder
  • Double Lifelines with Gates Port and Starboard
  • Mooring Cleats, Two Fore and Aft
  • Large Anchor Roller on Foredeck
  • Molded In Anchor Locker for Below Deck Chain and Rode Storage
  • Stainless Steel Handrails on Cabin Top
  • Stern Rail with Observation Seats
  • Removable Helm Seat
  • Hot & Cold Shower Mounted in Transom Boarding Area
  • Line Storage Cleats
  • L.E.D. Cockpit Light
  • Molded In LP Gas Locker with ( 1 ) 10 lb Tank
INTERIOR
  • Varnish Finish On Interior Teak
  • Veneer Bulkheads with Solid Teak Trim
  • Solid Teak Trim Doors, Teak Louvers Doors on Cabinets, Cedar lined Hanging Lockers
  • Chart Table with Adjustable Chart Light
  • Teak and Holly Textured Laminate Sole
  • Dining Table
  • Fabric Covered Interior Cushions
  • ( 3 ) Fixed Ports in Hull
  • ( 4 ) 0pening Ports with Screens
Galley
  • Refrigeration, D.C. Powered System with Freezer Compartment
  • Stainless Steel Sink, Polished
  • Single Lever Faucet with Pullout Sprayer
  • Large Top Loading Storage Bin with Rack
  • Utensil Drawer
  • Large Storage Cabinets in Galley
  • Two Burner Stove with Oven, Stainless Steel, L.P.G. with Auto Ignition
PLUMBING SYSTEM
  • Hot & Cold Pressure Water Distribution System
  • Manual Bilge Pump
  • Electric Bilge Pump with Float Switch
  • Marine Head with Holding Tank and Deck Outlet
  • Water Heater with A.C. and Engine Heat
  • Exchange Elements
ELECTRICAL SYSTEM
  • Marine Battery Charger
  • Deck Light and Steaming Light on Mast
  • Anchor Light at Masthead
  • 12 Volt Lighting Throughout
  • Custom 110 Volt AC/12 Volt DC Electric Panel
  • Circuit Breakers for AC Electrical Panel
  • Battery Condition Meter
  • Adjustable L.E.D. Cabin Lights
  • AC Duplex Receptacles Throughout
  • AC Dockside Power with Outlets and Polarity Indicator and Circuit Protection
  • DC Electrical System with Two Batteries, Selector Switch and Panel Circuit Protection
  • ( 1 ) 110V 30 amp Shore Power Cord
  • Galvanic Isolator

Disclaimer
The Company reserves the right to make changes to the above noted vessel description and pricing without notice. This vessel is offered for sale by the Company subject to E&OE and withdrawal without notice.
